Filter Cloth

Filter Cloth

Short Description:


Product Detail

Product Tags

Features

The filter cloth has been widely used for industrial solid/liquid filtration in the equipments of plate and frame filter press, chamber press and other presses, for its high strength and excellent chemical resistance.

The most frequently using materials are polypropylene, polyester, etc.The filter precision can reach less than 1 micron

Table : Chemical resistance

Fibre Material

Strong Acids

Weak Acids

Strong Alkalis

Weak Alkalis

Solvents

Oxidising  Agents

Hydrolysis

PET (Polyester)

Good

Good

Poor

Fair

Good

Very Good

Poor

PP (Polypropylene)

Very Good

Very Good

Very Good

very Good

Very Good

Good

Very Good

Specifications

Series Model No. Density
(Warp/Weft counts/10cm)
Weight
(g/cm3)
Bursting Strength
(Warp/Weft)
(N/5 X 20cm)
Air Permeability
(L/m2.s)
Construction
Polyester Staple Fabric 3927 156 / 106 535 3900 / 2600 18 P
758 194 / 134 330 2400 / 1750 100 P
747 232 / 157 248 2000 / 1350 120 P
5926 260 / 202 610 4100 / 4000 54 T
728 246 / 310 360 1900 / 2300 180 T
Polyester Long Thread Fabric 260 205 / 158 258 2100 / 1650 45 P
240 228 / 184 220 2350 / 920 80 P
130 260 / 217 126 1350 / 750 130 P
621A 193 / 130 340 2900 / 1950 55 P
Polypropylene Long Thread Fabric 750A 204 / 110 395 5060 / 2776 47 P
750B 251 / 149 465 4491 / 3933 37 T
750AB 337 / 210 720 6718 / 5421 24 T
521 211 / 151 300 2300 /1850 70 T
Note: P - Plain, T - Twill
