Activated Carbon Fiber (ACF) Pleated Filter Cartridge.jpg

Activated Carbon Fiber (ACF) Pleated Filter Cartridge

◆ Made of excellent activated carbon fiber and polypropylene components for high precision filtration

◆ Excellent ability to remove the odor, color and chlorine in liquid

◆ High dirt holding capacity and little carbon fiber release

◆ Broad chemical compatibility, resistant to acids and bases

◆ No hazardous substances releasing

It delivers stable and efficient purification performance for critical liquid treatment, complying with food-grade and pharmaceutical standards to ensure end-product safety. Lightweight and easy to install & replace, it minimizes maintenance downtime and operational costs while boasting long service life. Ideal for both batch and continuous processing, it ensures consistent decolorization and impurity removal without secondary pollution, serving as a reliable solution for your high-purity filtration needs.
    Contact us
    product details
    product description

    Specifications

    Materials Of Construction Filter Media: Activated Carbon Fiber (ACF)
    Support Layers: Polypropylene
    Micron Rating: 1.0, 3.0, 5.0um
    Inner core: Polypropylene
    Outer Cage, End caps: Polypropylene
    Seal Method: Thermal Bonded, No Adhesives
    O-rings/gaskets: Silicone, Nitrile, EPDM, Viton, etc
    Cartridge Dimensions Outer Diameter 69mm(2.75'')
    Inner Diameter 33mm(1.30'')
    Length(based on DOE end caps) 10"- 254mm, 20"- 508mm, 30"-762 mm, 40"- 1016mm
    Filtration Area(m2) 0.5 m2 per 10''
    Operating conditions Normal Operating Temperature: Up to 50℃ (122℉)
    Max.Operating Temperature.: 80℃ (176℉) at △P≤1.0 bar (14psi)
    Max. Differential Pressure
    Normal Flow direction: 4.2 bar (60 psi) at 25℃ (77℉)
    Reverse flow direction: 2.1 bar (30psi) at 25℃ (77℉).
    PH Value compatibility: 2-13
    Sterilization: Flush with hot water at 82℃(180℉) for 30 minutes
    Cartridge Safety Endotoxin: ＜0.25 EU/ml
    Extractables: 0.03g / 10"

    Order Information

    PRODUCT MICRON ADAPTER LENGTH O-RING / GASKET
    ACF 100-1um
    300-3um
    500-5um    		 AA- DOE
    CN-226/FIN
    BN-222/FIN
    BF-222/ FLAT SEAL
    CF-226/FLAT SEAL
    EN-222 three locking ears /Fin    		 10-10"
    20-20"
    30-30"
    40-40"
    05-5"
    Other-XX    		 S-silicone; N-nitrile
    E-epdm; T-teflon (encaptulated)
    V-viton
    How to Order?- Example
    Micron:5um; Length:10"
    ADAPTER: DOE; Gakset: Silicone.
    Selection Code is: ACF500AA10S

    Table: Typical water flow rate (10")

    Activated Carbon Fiber (ACF) Pleated Filter Cartridge

    Typical Applications

    • Remove the color of intermediates in pharmaceuticals industry

    • Organic impurities, chlorine and heavy metal ions removal in bottled water industry

    • Alcohol clarification

    • Remove the color in the organic solvent.
